TECHNICAL DATA OF THE BMW X5.

Select model

Weight

Unladen weight EU in kg 2,135-2,250
Max. permissible weight in kg 2,800-3,050
Permitted load in kg 740-875
Permitted axle load front/rear in kg 1,280-1,580/1,580-1,870
Luggage capacity min. (seats up or roof down) in l 550-650
Luggage capacity max. (seats down or roof up) in l 1,770-1,870
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,500-3,500
Trailer load 12% (braked) in kg 2,500-3,500

Engine

Cylinders/valves 6/4
Capacity in ccm 2,998
Stroke/bore in mm 94,6/82,0
Engine power in kW (hp) at 1/min 254-250 (333-340)/5,500-6,250 - 5,500-6,500
Engine torque (Nm) at 1/min 450/1,600-4,800 - 1,500-5,200
Compression ratio : 1 11.0

Performance

Top speed in km/h 241-243
Acceleration 0–100 km/h in s 5.9-5.5
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 10.9
Extra–urban in l/100 km 8.3-8.2
Combined in l/100 km 9.2
CO2 combined emissions in g/km 211-210
Electricity consumption combined in kWh/100km -
Tank capacity, approx. in l 83

Wheels

Tyre dimensions front 265/50 R19 110 W XL
Tyre dimensions rear 265/50 R19 110 W XL
Wheel dimensions and material front 9 J x 18 inches, light-alloy
Wheel dimensions and material rear 9 J x 18 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (PS) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (PS) -
Combined torque Nm -
Including of /content/bmw/marketZA/bmw_co_za/en_ZA/publicPools/teaser-pool/medium-teasers/tyre-energy-lables/jcr:content/par-4col/wideteaser_67 failed
​

Global shortages on standard and optional equipment.

  • Please note that certain standard and optional equipment may not be available on selected vehicles at present. Please check the listed features on your vehicle when placing your order and confirm the exact delivery date after placing the order with your preferred Retailer, as delays are possible.

​

Fuel consumption, electricity consumption and CO2 emissions of the BMW X5.

  • BMW X5 xDrive40i
    Fuel consumption in l/100 km (combined): 9.2
    CO2 emissions in g/km (combined): 211-210

    Official data on fuel consumption, CO2 emissions, power consumption and electric range were determined in accordance with the mandatory measurement procedure and comply with Regulation (EU) 715/2007 valid at the time of type approval. In case of a range, figures in the WLTP take into account any optional equipment. For newly type-tested vehicles since 01.01.2021, the official data no longer exist according to NEDC, but only according to WLTP. For more information on the WLTP and NEDC measurement procedures, see www.bmw.de/wltp.

    For more information on the official fuel consumption and official specific CO2 emissions of new passenger cars, see the ‘Guide to Fuel Consumption, CO2 Emissions, and Electricity Consumption of New Passenger Cars’, which is available free of charge at all sales outlets, from Deutsche AutomobilTreuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern- Scharnhausen, and at www.dat.de/co2
